Product Description:
The SDS520 possesses precise spectral characteristics, with a peak
wavelength fixed at 520.0±1.0nm, within the green spectrum region
where the human eye is highly sensitive. It delivers high
brightness and pure color, providing a clear and natural visual
experience for end products. Its chromaticity coordinates are
precisely controlled within the range of x=0.2490±0.003 and
y=0.6461±0.003, resulting in excellent color consistency and
minimal batch-to-batch deviation, effectively avoiding the uneven
color distribution issues that occur in mass production of
high-power LED products. Simultaneously, this product exhibits
highly efficient absorption of blue light chips in the 445~465nm
wavelength band, demonstrating outstanding light conversion
efficiency. It maximizes the conversion of blue light emitted by
the chip into green light, reducing light energy loss and
significantly improving the overall luminous efficacy of LED
devices.
Applications:
Features:
Model Number: SDS520
Place of Origin: CHINA
Certification: CE
Minimum Order Quantity: 100G
Price: Negotiable
Packaging Details: 100g or 1000g
Delivery Time: 5-10 days
Payment Terms: TT/Western Union Payment/
Supply Ability: 10000/Month
Application: LED Lighting
Optical transparency: High
Chemical composition: M2SiO4:Eu2+:Eu2+(M=Ca,Sr,Ba)
Color: green
Luminous efficiency: 134Lm/W
In terms of particle size control, the SDS520 employs advanced
airflow classification technology to achieve a narrow particle size
distribution design, with D50=15.0±2.0μm, including measured
D10=5.614μm and D90=15.21μm. This uniform particle size
distribution ensures good mixing and dispersion with encapsulation
materials such as silicone and epoxy resin during the encapsulation
process, avoiding luminous efficiency reduction or uneven light
spot caused by particle agglomeration. The product exhibits
extremely strong stability in harsh environments such as high
temperature and high humidity. Long-term aging tests have verified
that its luminous intensity decay rate is far lower than the
industry average. After 2000 hours of continuous operation at
85℃/85% RH, the light decay is still controlled within 5%, ensuring
the long service life of the LED device.
Special Lighting and Optoelectronic Equipment
Medical Lighting: Used in surgical shadowless lamps, endoscopic
lighting, and other equipment. Its high stability and flicker-free
characteristics reduce light interference with medical operations.
The green light component can help distinguish human tissues,
improving surgical accuracy.
Decorative Lighting: Suitable for stage lights, holiday decorative
lights, automotive ambient lights, etc. It can achieve
high-saturation green light output, and with RGB color matching
schemes, it meets diverse color display needs.
Optoelectronic Sensing: Used in fluorescence sensors, biological
detection equipment, etc. Stable luminescence characteristics and
high quantum yield can improve the sensitivity and accuracy of
detection equipment.
Customization:
Shenzhen Mengzhi Technology Co., Ltd. specializes in fluorescent
materials, adhering to the philosophy of "Light your life, light
your future." We offer flexible, customized LED phosphor services,
focusing on meeting the personalized needs of various scenarios.
Our core product, europium-doped silicate phosphor (SDS530-11),
forms the basis for customization. Particle size can be precisely
controlled according to the buyer's specific parameter
requirements, from fine particle size to specific distribution
ranges, breaking the limitations of fixed standards.
Customized products maintain lead-free and environmentally friendly
characteristics, strictly complying with RoHS standards. They
possess high color consistency and stable optical performance, with
key parameters such as peak wavelength and chromaticity coordinates
compatible with mainstream 445~465nm blue LED chips. Whether for
high-power packaging, display devices, or special optoelectronic
devices, customized particle size optimization improves dispersion
and luminous efficiency, adapting to various packaging processes. A
professional team provides full-process support, from parameter
confirmation to efficient production delivery, ensuring a precise
match between customized products and needs, providing you with
exclusive fluorescent material solutions that combine quality and
adaptability.
Support and Services:
The green LED phosphor powder is a high-quality product that is
designed to provide excellent performance and reliability for a
variety of applications. Our technical support team is available to
help you with any questions or issues you may have with the
product. Our services include:
- Product installation and setup
- Troubleshooting and problem resolution
- Product maintenance and repair
- Product updates and upgrades
- Technical consultation and advice
We are committed to providing our customers with the highest level
of support and service. If you have any questions or concerns about
our product or services, please do not hesitate to contact us.
Packing and Shipping:
Product Packaging:
The Green LED phosphor powder product will be packed in a tightly
sealed, moisture-proof container to prevent any damage during
transportation. The container will be labeled with the product
name, quantity, and any necessary warning labels.
Shipping:
The phosphor powder product will be shipped via a reliable and
secure courier service to ensure safe and timely delivery. The
shipment will include all necessary documentation, such as the bill
of lading and customs declarations. Customers will receive a
tracking number to monitor the progress of their shipment.
FAQ:
1. What is the brand name of the red LED phosphor powder?
A: The brand name is Silicate greenLED phosphor.
2. What is the model number of the red LED phosphor powder?
A: The model number is SDS520
3. Where is the green LED phosphor powder manufactured?
A: The product is made in China.
4. Does the red LED phosphor powder come with a certification?
A: Yes, it comes with a CE certification.
5. What is the minimum order quantity of the green LED phosphor
powder?
A: The minimum order quantity is 100g.
6. What is the price of the green LED phosphor powder?
A: The price is negotiable.
